HPE Aruba Networking CX 6405 v2 Switch hanterad Strömförsörjning via Ethernet (PoE) stöd 7U

  • Brand: HPE
  • Category:
  • SKU: R0X26C
  • EAN: 0190017537382 0190017537399
HPE Aruba Networking CX 6405 v2 Switch, hanterad, Strömförsörjning via Ethernet (PoE) stöd, Rackmontering, 7U

Trade Prices

Distributor Product SKU Stock Updated Price
Also Sweden

HPE Aruba 6405 v2 Switch

 46128145 Register free see stock
EET Sverige AB

Aruba 6405 Managed Grey

 W128289210
Tech Data - EMEA

HPE Aruba CX 6405 v2 - Switch - L3 - Administrerad - fr?mre till bakre luftfl?de - rackmonterbar - f?r P/N: R0X27C, R0X38C, R0X39C, R0X40C, R0X41C, R0X42C, R0X43C

 7744172
Tech Data - Sweden

HPE Aruba CX 6405 v2 - Switch - L3 - Administrerad - främre till bakre luftflöde - rackmonterbar - för P/N: R0X27C, R0X38C, R0X39C, R0X40C, R0X41C, R0X42C, R0X43C

 7744172

Related Products

Description

HPE Aruba Networking CX 6405 v2 Switch. Switch typ: hanterad. Switch kapacitet: 14000 Gbit/s. Kommunikationsstandarder: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt. Strömförsörjning via Ethernet (PoE) stöd. Rackmontering, Formfaktor: 7U

Specifications

Management features
Switch typhanterad
Nätverk
KommunikationsstandarderIEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
10G stödJa
Data transmission
Switch kapacitet14000 Gbit/s
Genomströmning20000 Mpps
Design
RackmonteringJa
StaplingsbarJa
Formfaktor7U
Prestanda
Processorfrekvens1800 MHz
MinnestypDDR4-SDRAM
Internminne8000 MB
Flashminne32000 MB
Inbyggd processorJa
ProcessorARM Cortex-A72
StaplingsbarJa
Strömtillförsel
Strömförsörjning ingårJa
AC-inspänning200 - 240 V
Meddelane om effektförbrukningR0X35A PSU: 1800W at 200–240 VAC, 1100W at 110–127 VAC R0X36A PSU: 3000W at 200–240 VAC, 1500W at 110–127 VAC
StrömkällaAC
Power over Ethernet (PoE)
Strömförsörjning via Ethernet (PoE) stödJa
Övrigt
Latens1G: 5.32 μSec 10G: 1.48 μSec 25G: 2.78 μSec 40G: 1.31 μSec 100G: 1.42 μSec
Prestandahantering1 x RJ‑45 console port 1 x USB‑C console port 1 x OOBM port 1 x USB Type-A host port HPE Aruba Networking Management Software (AirWave) HPE Aruba Networking Central HPE Aruba Networking Switch Multi-Edit Software HPE Aruba Networking CX Mobile App Command-line interface SNMP v2c/v3 RMON
Minne och processorCPU Management Module: Quad-core Arm Cortex™ A72 at 1.8 GHz Line Cards: Dual-core Arm Cortex™ A72 at 1.8 GHz (R0X38A‑R0X45A and R0X38B‑R0X40B) Line Cards: Quad-core Arm Cortex™ A72 at 1.8 GHz (R0X38C‑R0X45C, S0E48A, S1T83A) Memory and flash Management Module: 16 GB DDR4 ECC memory: 32 GB eMMC Flash memory Line Cards: 4 GB DDR4 memory (R0X38A‑R0X45A and R0X38B‑R0X40B) Line Cards: 8 GB DDR4 memory (R0X38C‑R0X45C, S0E48A, S1T83A)
FläktTwo field replaceable system fan trays
Vikt (imperial)53,6 kg (118.2 lbs)
Externa anslutningarHigh speed, non-blocking 1/10/25/40/50/100GbE ports 10 I/O module slots maximum depending on model
Miljökrav
Temperatur vid drift0 - 45 ° C
Vikt & dimension
Bredd528,8 mm
Djup442,6 mm
Höjd448,5 mm
Vikt53,5 kg
